HCA Pump · H Serisi · Pompalar
| Category | Description |
|---|---|
| Usage Areas |
• Cutting, turning, milling, boring, grinding and similar applications of the machine tools, • Erosion machines, • Circulation systems. HCAPumps are used for pumping of cutting / cooling fluids. |
| Suitable Fluids |
• Coolants, • Cutting oils, • Grinding oils, |
| Properties of Pumped Fluids |
• Fluid temperature 0...80 °C • Kinematic viscosity 1...30 mm2/s |
| Materials |
Pump body : Cast iron - DIN GG 25 Bottom plate : Sheet iron Diffuser : Stainless steel - DIN 4301 (AISI 304) Impeller : Stainless steel - DIN 4301 (AISI 304) Stage cover : Stainless steel - DIN 4301 (AISI 304) Pump shaft : Stainless steel - DIN 4401 (AISI 316) O-ring : Viton Mechanical seal : C - SiC - Viton TC - TC - Viton (Optional) |
| Electric Motor |
Electric motor : 3 phase induction motor IE3 - 2 pole Protection degree IP 55 |
