| Application Areas |
• Cutting, turning, milling, boring, grinding and similar applications of the machine tools,
• Cooling systems,
• Circulation systems. HDA Pumps are used for pumping of cutting / cooling fluids. |
| Pumped Fluids |
- • Coolants,
• Cutting oils,
• Grinding oils
|
| Fluid Properties |
- Fluid temperature should be between 0°C and 80°C.
- Kinematic viscosity should be between 1 and 30 mm²/s.
|
| Materials |
- Pump body: Cast iron - DIN GG 25
- Lower part: Sheet metal
- Diffuser: Stainless steel - DIN 4301 (AISI 304)
- Impeller: Stainless steel - DIN 4301 (AISI 304)
- Filter: Stainless steel - DIN 4301 (AISI 304)
- Pump shaft: Stainless steel - DIN 4401 (AISI 316)
- O-ring: Viton
- Mechanical seal: C - SiC - Viton (Optional: TC - TC - Viton)
|
| Electric Motor |
- 3-phase asynchronous motor
- 2 poles
- Protection rating: IP 55
|
| Other Features of the HDA Pump |
- Easy installation and maintenance
- Wide performance range
- Durable and robust structure
- Resistance to abrasive fluids (optional)
- Quiet operation
|
