Fluids:

• Cooling fluids,
• Cutting oils,
• Grinding oils,
• Water,
• Fluid temperature: 0...80 °C
• Kinematic viscosity: 1...30 mm²/s

Materials:

Pump body: Cast iron - DIN GG 25
Base: Cast iron - DIN GG 25
Diffuser: Stainless steel - DIN 4301 (AISI 304)
Impeller: Stainless steel - DIN 4301 (AISI 304)
Strainer: Stainless steel - DIN 4301 (AISI 304)
Pump shaft: Stainless steel - DIN 4401 (AISI 316)
O-ring: Viton
Mechanical seal: C - SiC - Viton
TC - SiC - Viton (Optional)
TC - TC - Viton (Optional)
Electric motor: 3-phase asynchronous motor
2 poles
Protection class: IP 55
