8 Poles (750 rpm) - 3 Phase Vibration Motors - Products

MECHANICAL SPECIFICATIONS						ELECTRICAL SPECIFICATIONS
RPM	TYPE	Centrifugal Force		Static Moment	Weight	Nominal Voltage	Max. Current	Max. Input Power
50 Hz		KG	N	kgmm	KG	V	A	Kw
750	VD 8-200	195	1913	310	28	230/400	1,38/0,80	0.43
	VD 8-300	290	2845	461	33	230/400	1,55/0,90	0.43
	VE 8-520	510	5003	811	64.5	230/400	2,68/1,55	0.5
	VE 8-780	765	7505	1217	73	230/400	2,77/1,60	0.55
	VG 8-1000	1000	9810	1590	92	230/400	3,98/2,30	0.95
	VG 8-1200	1200	11772	1908	99	230/400	4,67/2,70	1.1
	VH 8-1500	1500	14715	2386	119	230/400	6,92/4,00	1.5
	VK 8-2200	2200	21582	3499	174	230/400	12,30/7,10	2.5
	VK 8-2650	2650	25997	4214	184	230/400	12,30/7,10	2.5
	VL 8-3700	3711	36405	5902	260	400/690	11,00/6,35	5
	VL 8-4500	4598	45106	7313	277	400/690	11,00/6,35	5
