GPH Pompa - Axial Impeller Pumps - Pumps
| Category | Description |
|---|---|
| Application Areas |
• GPH pump has an additional axial impeller, • It is used for pumping the liquid foam resulting from high-speed machining operations, • Pumping metal chips together with the fluid by mixing, • Filtration systems, • Hot liquid applications, • GPH Pumps are used for pumping of cutting / cooling fluids in circulation systems. |
| Pumped Fluids |
• Coolants, • Cutting oils, • Grinding oils |
| Fluid Properties |
• Fluid temperature 0...80 °C |
| Materials |
Pump body : Cast iron - DIN GG 25 Volute : Cast iron - DIN GG 25 Impeller : Brass Axial (front) impeller : Investment casting steel - AISI 4140 (DIN 42CrMo4) O-ring : Viton Pump shaft : Engineering steel - AISI 1040 (DIN C35) |
| Electric Motor |
Electric motor : 3 phase induction motor IE3 - 2 pole Protection degree IP 55 |
