JE Pompa - JE Pump - Pumps
| Category | Description |
|---|---|
| Usage Areas |
• Non-clogging type pump is used for pumping liquids which contains 35 mm metal chips. • Filtration systems, • Treatment systems, • Cutting, turning, milling, boring, grinding and similar applications of the machine tools, • Cooling systems, • Circulation systems. JE Pumps are used for pumping of cutting / cooling fluids. |
| Suitable Fluids |
• Coolants, • Cutting oils, • Grinding oils, • Dirty industrial water and refining, • Chip contains liquids (max. 30 mm) |
| Properties of Pumped Fluids |
• Fluid temperature 0...80 °C • Kinematic viscosity 1...30 mm2/s (Please contact us for higher viscosities) |
| Materials |
Pump body : Cast iron - DIN GG 25 Volute : Cast iron - DIN GG 25 Impeller : Cast iron - DIN GG 25 Pump shaft : Engineering steel - AISI 1040 (DIN C35) |
| Electric Motor |
Electric motor : 3 phase induction motor IE3 - 2 pole Protection degree IP 55 |
