KEP 450 Pump - KEP Series - Pumps
| Category | Description |
|---|---|
| Application Areas |
• Cutting, turning, milling, boring, grinding and similar applications of the machine tools, • Filtration systems, • Circulation systems. • KEP Pumps are used for pumping of cutting / cooling fluids. |
| Pumped Fluids |
• Coolants, • Cutting oils, • Grinding oils, • Chip containing liquids (max. 12 mm) |
| Fluid Properties |
• Fluid temperature 0...60 °C |
| Materials |
Pump body : Cast iron - DIN GG25 Motor Flange : Cast iron - DIN GG25 Impeller : Cast iron - DIN GG25 Shaft : Stainless steel - AISI 420 (DIN 1.4021) Mechanical Seal : C-SiC-Viton |
| Electric Motor |
3 phase induction motor - 2 pole, 1 phase induction motor (Optional)Protection degree IP 54 |
| Other specialities |
|
