Usage Areas:

• Machine Tools: The LP 125 Pump is used for pumping cooling and lubrication fluids, enabling more precise and smooth operations such as cutting, turning, milling, drilling, and grinding in machine tools.
• Filtration Systems: The LP 125 Pump circulates fluid in filtration systems, ensuring a more efficient filtration process.
• Circulation Systems: The LP 125 Pump ensures continuous fluid circulation within the system, making it suitable for various processes.
• Air Conditioning Systems: The LP 125 Pump facilitates water circulation in air conditioning systems, enhancing heat transfer and cooling efficiency.

Pumped Fluids:

The LP 125 Pump can handle a wide range of fluids:

• Cooling fluids
• Cutting oils
• Grinding oils
• Water
• Fluids containing solid particles up to 5 mm

Fluid Properties:

• Fluid temperature should be between 0°C and 60°C.
• Kinematic viscosity should range from 1 to 90 mm²/s.

Pump Materials:

The LP 125 Pump is manufactured using high-quality materials for durability and long service life:

• Pump body and motor flange: Cast iron - DIN GG25
• Impeller: Cast iron - DIN GG25
• Shaft: Stainless steel - AISI 420 (DIN 1.4021)
• O-ring: Viton
• Mechanical seal: SiC-SiC-Viton

Electric Motor:

The LP 125 Pump operates with three-phase asynchronous motors and has an IP 54 protection rating. It is resistant to challenging working conditions. A 2-pole motor option is offered as standard.

Other Features of the LP 125 Pump:

• Easy installation and maintenance
• Wide performance range
• Durable and robust construction
• Ability to pump solid particles up to 5 mm
• Quiet operation
