2-4 Poles Micro Vibration Motors - Micro Vibration Motors - Products
| MECHANIC SPECIFICATIONS | ELECTRICAL SPECIFICATIONS | |||||||||
| RPM | TYPE | Centifugal Force | Static Moment | Weight | Nominal Voltage | Max. Current | Capacitor | Max. Input Power | ||
| 50 Hz | KG | N | kgmm | KG | V | A | µF | W | ||
| threephase | 3000 | VX 20 | 21 | 206 | 2,10 | 1,6 | 400 | 0,11 | - | 21 |
| VY 40 | 39 | 383 | 3,88 | 2,6 | 400 | 0,18 | - | 40 | ||
| VY 60 | 59 | 579 | 5,86 | 2,7 | 400 | 0,18 | - | 40 | ||
| 1500 | VY 25 | 25 | 245 | 9,94 | 3,0 | 400 | 0,18 | - | 56 | |
| monophase | 3000 | VX 20 M | 21 | 206 | 2,10 | 1,6 | 230 | 0,12 | 1 | 25 |
| VY 40 M | 39 | 383 | 3,88 | 2,7 | 230 | 0,24 | 4 | 50 | ||
| VY 60 M | 59 | 579 | 5,86 | 2,8 | 230 | 0,24 | 4 | 50 | ||
| VZ M | 4 | 39 | 0,4 | 0,9 | 230 | 0,12 | - | 20 | ||
| 1500 | VY 25 M | 25 | 245 | 9,94 | 3,1 | 230 | 0,28 | 4 | 58 | |
