HD Pump - H Series - Pumps

Category	Description
Application Areas	• Cutting, turning, milling, boring, grinding and similar applications of the machine tools, • Erosion machines, • Circulation systems. HD Pumps are used for pumping of cutting / cooling fluids.
Pumped Fluids	• Coolants, • Cutting oils, • Grinding oils,
Fluid Properties	Fluid temperature should be between 0°C and 80°C. Kinematic viscosity should be between 1 and 30 mm²/s.
Pump Materials	Pump body : Cast iron - DIN GG 25 Inlet body : Cast iron - DIN GG 25 Diffuser : Stainless steel - DIN 4301 (AISI 304) Impeller : Stainless steel - DIN 4301 (AISI 304) Stage cover : Stainless steel - DIN 4301 (AISI 304) Pump shaft : Stainless steel - DIN 4401 (AISI 316) O-ring : Viton Mechanical seal : C - SiC - Viton TC - TC - Viton (Optional)
Electric Motor	3-phase asynchronous motor 2 poles Protection rating: IP 55
