| Application Areas |
- Machine Tools: Provides more precise and smooth machining in cutting, turning, milling, drilling, and grinding processes on machine tools.
- Cooling Systems: Ensures the circulation of fluid in cooling systems, enabling more efficient heat transfer and cooling operations.
- Circulation Systems: Facilitates continuous fluid circulation within the system, used in various processes.
- Cutting-Cooling Fluid Pumping: Ideal for pumping cutting-cooling fluids, ensuring cooler and more efficient cutting operations.
|
| Pumped Fluids |
• Coolants,
• Cutting oils,
• Grinding oils,
• Industrial water,
• Chemical liquid
• Fluid temperature 0...60 °C
• Kinematic viscosity 1...30 mm2/s
|
| Materials |
Pump body : PP
Volute : PP
Impeller : PP
Pump Shaft : Engineering steel - AISI 1040 (DIN C35)
Stainless steel - AISI 316 (DIN 4401) (Optional)
Stainless steel - AISI 420(DIN X20Cr13) (Optional)
Strainer : PE (Optional) |
| Electric Motor |
Operates with 3-phase asynchronous motors and has an IP 54 protection rating, making it resistant to challenging working conditions. A 2-pole motor option is available.GTRGEGEHG |
| Other Features |
- Easy installation and maintenance
- Wide performance range
- Durable and robust structure
- Radial blade impeller
- Ideal for filtered fluids
- Quiet operation
|
